STEPCRAFT Q.408 CNC-System

SKU: 11340

Category: Ready-to-Run

This item is currently not available.

15.000,00 €

incl. 19% VAT , plus

Description

The Q-Series sets new standards in the computer-aided individual and serial production. The powerful CNC system unites efficiency, precision and quality with modern industrial design and has been specifically constructed for industrial application. With production speeds of up to 12 m/min, a large variety of materials such as woods, plastics, aluminum, brass, carbon, and composites can be efficiently and precisely processed.

Intelligent Mix of Materials
Innovative solutions are combined with smart technology. This can be seen, for example, in the intelligent mix of heavy-duty aluminum extrusions and steel components on constructional highly-stressed areas. While the machine frame of the Q.408 is reinforced with six aluminum crossbars for an optimal distribution of forces, the gantry uprights are made of a 5-layered, powder-coated steel construction. Additionally, the linear guide system relies on the All-Steel Motion System^TM with Ø 20 mm hardened steel shafts and, thus, guarantees a high load capacity.

Solid Drive Unit
The Q.408 contains a solid drive unit, consisting of two actively-cooled stepper motors, which move the ball screw drives including revolving nuts. This ensures maximum agility and precision. Additional useful features are the Z-axis that is equipped with six T-slots for the variable attachment of different tools, the electronic expansion box for the easy connection of signal-dependent components, the machine table that comes standard with aluminum T-slots offering the most flexibility when fixing your workpieces and accessories as well as the LED machine illumination for the optimal lighting of the working space. Furthermore, the Q-Series can be individually extended with a multitude of optional accessories.

OneTech^TM Quality Philosophy
All systems of the Q-Series are manufactured according to our unique OneTech^TM quality philosophy. This means that one machine is completely handcrafted and checked by one technician. Only after successful testing of all functionalities will a machine of the Q-Series receive the personal OneTech™ quality seal and will leave our site with the respective test protocol and workpiece.

Note: The MDF T-Slot Table is not suited for the use with liquids because it can damage the wood.

Note: The STEPCRAFT Q.408 can only be purchased together with the corresponding machine stand.

CE compliant
Supplied with all components necessary for operation
Control electronics for an easy connection to the computer via USB or parallel interface
Steel components on constructional highly-stressed areas
Ball screw drive on X and Y including revolving nuts
Concealed cable routing trhough high-quality energy chains
Complete encapsulation of the linear guides with easy maintenance access
Machine table with open pass-through design on the Y-axis allows processing of long sheet materials
All-Steel Motion System^TM with Ø 20 mm hardened steel shafts
Machine frame reinforced with 10 crossbars
Standard machine table out of white coated MDF boards with aluminum T-slots
Z-axis with six T-slots for the variable attachment of different tools
Highest quality cabling capable of up to 10 million bending cycles
Made in Germany
1 year guarantee
CNC System Overview

Overall Size (X, Y, Z): 1596 x 2724 x 870 mm
Working Space (X, Y, Z): 1223 x 2446 x 145 mm
Clamping Surface: 1400 x 2700 mm
Repeatability: +/- 0,015 mm
Programmable Resolution: 0,005 mm
Backlash: +/- 0,015 mm
Max. Speed (per linear axis): 12 m/min
Max. Speed (diagonal travel): 17 m/min
Maximum Speed: 200 mm/s
Drive Unit: Ball Screw Drive on X and Y including revolving ball screw nuts
Linear Drive: All-Steel Motion System^TM with hardened guide shafts / rollers
Weight: 275,2 kg (606.7 lbs)
Machine table: Integrated T-Slot Table (optional aluminum)
Input voltage (AC): 100 - 240 V
Output voltage (DC): 48 V
Interface: USB / Parallel (LTP1)

CNC machine available without control software or with WinPC-NC or UCCNC.

Ready-to-run system incl. all mechanical and electronic components
Operating instructions, machine operating manual
Test protocol and workpiece

PC with 1 GHz processor
USB interface
Windows® XP or higher(32/64 bit)
MAC OS X 10.3.9 or higher withWindows® emulation
